Chair Tilt Adjustment

Tilt with Adjustable Tilt Tension

Tilt provides the option to recline backward and adjust a limit definite by control plate and chairs mechanism. The adjustment is controlled by  modified by turning a round knob found under the seat to the front/side of the chair. Paddles or levers are to maintain tilt lock also can use a single rod or lever which requires pushed or pulled out to unlock or lock the tilt.

Once the tilt is positioned to unlock the tilt or reclines back a few degrees more relieving pressure from the pin or lock bar. Tilt lock is applied to lock tilt totally if the chair is in the upright position.

lumbar support

Lumbar Support Adjustment

One of the most important factor in choosing ergonomic chair is adjustable lumbar support.
These chairs are extremely helpful for people who spend the majority of their work day at a desk. People who perform most of their tasks on a computer can especially benefit from chairs that provide proper support for their backs.
The lumbar support should fit right in the natural curve of your spine, typically at the small of your back directly above your belt line. This adjustment is often built into the chair so you can adjust both the height of the chair back and the lumbar support at the same time. In some chairs, it's an independent adjustment.

seat-pan

Seat Pan Depth Adjustment

A seat pan with a sliding mechanism is a beneficial feature. This allows small and tall users to adjust the distance of the seat pan from the backrest. A person of smaller stature who sits on a long seat pan will experience pressure behind the knees, or will not benefit from the chair’s back support if he sits on the edge of the chair.  A person of larger stature who sits on a short seat-pan length will have inadequate support of the thighs causing higher contact pressure

synchro tilt

Synchro Tilt

The synchronous mechanism (synchro tilt) combines a movement of the backrest and a corresponding smaller movement of the seat. The movement of the backrest is thereby larger than the movement of the seat. This allows the user to recline while keeping their seat relatively level to the floor instead of the traditional “rocking chair” type recline.

armrest

Armrest Adjustment

Armrest height is one of the most common ergonomic chair adjustments. The armrest adjustment can help with upper back. This is usually controlled by a push of a button or a simple knob, allowing to tilt the armrests inwards or outwards to varying degrees until you find the position which adjusted to level of comfort. The chairs armrest are adjustable in 1D, 2D, 3and 4D which allows sitting close and working with arms relaxed.

headrest

Headrest Adjustment

Headrest adjustments provide support and comfort to the head and neck while in a reclined position, often keeping the head at a near-constant eye level with your computer monitor. The headrests are usually adjustable in height and angel to help head centered on the neck, not leaning forward.
